    Flexographic Printing 2 Lines Napkin Paper Machine With Jumbo Roll Embossing Folding

    Ask Lasest Price
    Brand Name : EAST
    Certification : ISO9001
    Supply Ability : 20 Sets per month
    Price : $19,500.00/set
    Payment Terms : L/C, T/T
    Delivery Time : 35-40days
    Model Number : 2 lines
    • Product Details
    • Company Profile

    Flexographic Printing 2 Lines Napkin Paper Machine With Jumbo Roll Embossing Folding

    Flexographic Printing 2 Lines Napkin Paper Machine With Jumbo Roll Embossing Folding


    Machine features


    1. Spiral crosswise cutting unit:spiral cutting blade can help to cutting at the same angle,small noise,and keep blades run longer.It helps to adjust and maintain easily.

    2. New design for the bottom cutting blade:there are absorb hope on the blades and the thickness of blades is 6mm that is strong enough for cutting .the tissue will adsorb on the blade and keep folding stable.


    3.Can add lamination and colors printing function(options)

    4. The machine is equipped with electrical shifting device,which can mark the sheet counts of each bundle required,making it easy for packaging elements,which can make the embossing patterns clearing and better.


    Machine Technical Parameter


    Machine Specification600mm
    Finished paper unfolded size330X330mm,±2mm
    Working speed1000-1300pc/min
    Power source380V,50 HZ
    Main motor4KW Delta frequency conversion
    Band saw cutting power1.5kw
    Jumbo roll diameter1200mm
    Jumbo roll paper material16.5-32g/single lay 13.5-18gdouble layers
    Folding type1/12 fold
    CountingElectronic counting, pneumatic splitting and stacking
    EmbossingOne set of steel to wool,with feeding roller
    Embossing roll surface width670mm
    Machine size7000*1400*1860 mm
    Electrical accessoriesDelta Inverter, Chint Electronic Components
    Pneumatic componentsOrdinary domestic cylinder

    Flexographic Printing 2 Lines Napkin Paper Machine With Jumbo Roll Embossing Folding





    FAQ


    Q: Can you provide the installation videos?

    A: Yes, we will provide.
    Q: What's the production time?

    A: Generally it is 40-60 working days, it depends on your customized requirements.

    Q: How long is your warranty?

    A: One year of the machine, wearing parts not included.
    Q: Can your company do customized machine?

    A: Yes we can. We have 3 experienced engineers to support customized designs.
    Q: How about your after-sales services?

    A: We offer online instructions or onsite if needed.
